Auto Page RF-425LCD - 5-Wire Reverse Polarity Door Locks; Adding Door Lock Actuators

8
5-WIRE REVERSE POLARITY
ADDING ACTUATORS
VIOLET UNLOCK... N/O (87)
BROWN UNLOCK SWITCH... N/C (87a)
LT. BLUE UNLOCK MOTOR... COMMON (30)
LT. GREEN LOCK MOTOR... COMMON (30)
VIOLET/RED LOCK... N/O (87)
20A
WHITE LOCK SWITCH...N/C (87a)
LOCK
UN
LOCK
12+ VOLTS
20A
12v B+
LOCK
UNLOCK
LOCK
UNLOCK
GROUND
LOCK
LOCK
UNLOCK
UNLOCK
FRONT DOORS
BACK DOORS
WHITE WIRE
&
BROWN WIRE
VIOLET WIRE
&
VIOLET RED
GREEN WIRE
BLUE WIRE
