ENGLISH - 17
Make sure that hole size is big enough to insert
all cables together by one and one
E-2
Place cable holder 30cm away from the rear center of the antenna. Apply friction tape 5mm from away
the outside of holder
E-3
E-1
Drill a 20mm hole (or larger) in the center of the
tape marking
D-2D-1
D. Fix mounting plate with 8 pcs of M6x15 bolt using allen wrench
E. Cable holder installation 1
Place the antenna on mounting plate and
tighten rmly each bolt by allen wrench
Parts required, allen wrench and eight(8) of
M6×15 bolt
To Next Page
