Typical Helmet Installation
ExternalControlButton(5)
Multifunction Button.
AutocomAirUnit(2)-Hiddeninneckcollar
Battery(3)-Hiddenininternalpadding
InternalWiringColourcoding:
Yellow = Speakers
Blue = Microphone
Red = Battery
Black = External Switch
Speakers(1)-Velcromountedinearvoidpadding
Microphone(4)-Boom
microphone. Mounted
internally, centrally fitted
close to mouth.
