AutoCrib C - Jam Error Code S4

AUTO CRIB
S
Code
Error Action Message
S3 Platter too
slow during
full speed part
of the move.
1. Take no action
2. Throw error
3. Lock the screen.
“Possible Jam on Platter r
X See Supervisor”
Move Cycle
Speed
Accel. Decel.
Ramp Ramp
Notes: An S3 error is usually a soft jam and is caused by an item that is pinched between the chain
and a sprocket. This almost always happens on the LSP or serpentine chain. The administrator
should remove the side panel and inspect the chain for any obstructions. Clear any obstructions and
restart the machine so it recalibrates.
Time
S3
Full speed part
Of move
Check 2
Check 1
Fetch Begins Fetch Ends
