AutoGyro Cavalon - Electrical Circuit Protection

Pilot Operating Handbook
Cavalon
SECTION 7
SYSTEM DESCRIPTION
AutoGyro_POH_Cavalon 915iS Revision 1.0 – Issue Date 08.MAY.2019 7-11
7.13 Electrical circuit protection
Fuse
description
Rating Protects Fuse type
Location
Main incoming
supply to
cockpit
40A Main positive supply
is fed to the starter
solenoid from the
battery. The supply
continues then
through the 40amp
fuse to the cabin.
Bolt in strip type,
MTA S.p.A.
“Midival” range
40A rating
Engine bay fuse
box, left side
within inner
firewall
Compressor 10A Only supplies the
pneumatic
compressor
CB Inst. Panel
Gen3 5A Aux generator CB Inst. Panel
Cockpit 5A All electrical gauges
(rotor and engine
rpm, oil pressure,
water and oil temps,
fuel gauge) and
warning lamps
CB Inst. panel
Radio 5A Radio (transceiver) CB Inst. panel
Transponder 5A Transponder CB Inst. panel
EFIS 10A Aspen PFD VFR or
other display
CB Inst. panel
Alt/Aux 10A Accessory
instruments
CB Inst. panel
GPS 5A GPS or iPad with
navigation software
CB Inst. panel
Pitot 5A Pitot heat CB Inst. panel
Lights (Day-
VFR variant)
5A Landing lights CB Inst. panel
Lights (Night-
VFR variant)
16A Landing lights CB Inst. panel
ACL 5A Nav and Strobe
lights
CB Inst. panel
Start 5A Starter relay and
SMD module
CB Inst. panel
Electric
Variable pitch
propeller
(where fitted)
16A Pop out circuit
breaker for propeller
and propeller
controller.
CB Inst. panel
Fan 10A Power supply to
engine cooling fan
CB Inst. panel
Trim 2A Supplies power to
the stick controls for
operating the
pneumatic solenoid
valves and the
compressor relay
CB Inst. panel
12v plug 5A Accessory socket CB Inst.panel
Heat 16A Electric seat heating CB Inst panel
