AUTOHELM Z219 - Figure 1 Exploded View

1. Wind vane
2. Wind vane head
3. 'O' ring (2 off)
4. Nut
5. Ribbon cable
6. SeaTalk cable
7. Main PCB
8. Body
9. Anemometer head
10. Cup assembly
Ribbon connector detail
Open
position
Closed
position
Red
Screen
Yellow
4
1
11
2
3
PL1
5
5
7
PL1
PL2
PL1
9
3
10
11
4
D2711-1
8
6
Figure 1 Exploded View
ST80 Active Wind Transducer
8 ST80 Active Wind Service Procedures 83067-1
Z219
