AUTOMATED EQUIPMENT RAM 280-F User Manual

RAM™ 280-F Frozen Fry Dispenser
Copyright © 2011 Automated Equipment LLC All rights reserved.
9
Dispenser Assembly (Models after and including s/n 28FR0802B0249)
Note: Before assembling the Dispenser it is recommended that all parts be cleaned, sanitized,
dry, and handled in a sanitary manner. Refer to the Cleaning Procedures (
page 12) for more
information.
Open the cabinet door. Accumulator doors are pre-installed. Install the left and right flap doors by
slipping them under the accumulator doors and seating the pivot pin into the plastic pivot blocks, as
shown above. (Accumulator Doors are hidden for clarity in Right Hand view).
Accumulator Housing Assembly
Install the left and right Accumulator Housings over the Accumulator Doors.
Pivot Block
