AUTOMATED EQUIPMENT RAM 280-F User Manual

RAM™ 280-F Frozen Fry Dispenser
Copyright © 2011 Automated Equipment LLC All rights reserved.
21
D08
Reset Refrigeration
Errors # 5, #6 & #7
Clears and resets any active refrigeration errors (errors 5, 6 &
7)
Display defaults to “Er. no”
Press up arrow, display will read “Er.YES”
Down button will return to “Er. no”
Press enter button to execute and return to D01.
D09
Actuate Outputs
Note: Basket Size
Buttons also function
as numbers
Note: The
refrigeration circuit
contains anti-short-
cycle protection.
Allows outputs to be turned on and off to aid in diagnosing
problems.
Display shows selected motor and command. (i.e. “d2 on”
indicates the right drum motor’s output is on.)
Use Basket Size Buttons to select an output:
1. Left Drum motor (d1)--Left Small Basket
2. Left Accumulator motor (A1)--Left Medium Basket
4. Right Drum motor (d2)--Right Small Basket
5. Right Accumulator motor (A2)--Right Medium Basket
6. Refrigeration compressor (rF)--Right Large Basket
Up arrow turns output on,
Down arrow turns output off.
Enter button closes function.
The display flashing “rF OFF” indicates the refrigeration
compressor cannot be restarted until the 2 minute short cycle
delay is met.
All outputs will turn off and return to normal operation when
exiting the function.
D10
Diagnostics Display
Note: See page 26
Shows status of all controller Inputs and Outputs while the
dispenser continues normal operation.
Display shows all activated Inputs and Outputs.(see page 26)
Size and Enter buttons function just as in main screen
during normal operation.
Up Arrow Button does nothing.
Down Arrow button will exit the function.
D11
Bypass Basket
Sensors
Note: Volatile setting.
(will reset each time
power is cycled)
Allows the dispenser to be used when a basket sensor has
failed.
Display will read “[bYP]” with alternating flashing brackets.
Use Basket Size buttons to select the side to be
bypassed.
Display will default to the current sensor condition.
Up arrow sets bypass mode. “[ YES” ( “YES]”)
Down arrow clears it. “[ no” (“ no]”)
Enter button executes selection, exits function and
returns to D01
D12
Bypass Weighing
Note: Volatile Setting
Disable the scale to allow other diagnostics to be performed
without wasting product.
Display will read “[SCL]” with alternating flashing brackets.
Use Size Keys to select the side to be bypassed.
Display will default to current scale status.
Up arrow turns the scale on for selected side.
“[ on” (“ on ]”)
Down arrow turns off the scale for selected side.
“[ OFF” (“ OFF ]”)
Enter button executes selection, exits function and
returns to D01
