Automation Technology C2-2040-GigE Hardware Reference Manual

C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 13
The C2-2040(HS)-GigE CMOS Imager Specifications
Parameters Specifications
Sensitivity 16000 LSB / µJ / cm
2
@ 550 nm
Maximum Spectral Response 0.290 A / (W nm) @ 665 nm
Resolution 2048 x 1088 pixels
Pixel Size 5.5 µm x 5.5 µm
Sensor Size 11.264 mm x 5.984 mm, diagonal: 14.638 mm
Sensor Format 2/3”
Sensor ADC Resolution 10 bit
Sensor Dynamic Range 90 dB with HDR
Max. Internal Full-Frame Rate 340 fps
Max. External Full-Frame Rate
(limited due to GigE bandwidth)
50 fps
Effective Frame / Profile Rate at
Max. Row Length
Number of Rows Effective Frame / Profile Rate (Hz)*
C2-2040HS-GigE C2-2040-GigE
8
16
32
64
128
256
512
1088
30720
19608
10638
5556
2841
1401
723
340
1401
1401
1401
1401
1401
1401
723
340
*with Frame Overhead Time (FOT)=2
