C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 59
Electrical Specifications of C2-I/O-Panel
• Inputs
TTL
 VIL, logic “0” Voltage < 1.5 V
 VIH, logic “1” Voltage > 3.5 V
Max. current 2 mA
HV
 VIL, logic “0” Voltage < 7.5 V
 VIH, logic “1” Voltage > 17.0 V
• Outputs
TTL
 VOL_TTL, logic “0” Voltage < 0.4 V
 VOH_TTL, logic “1” Voltage > 3.3 V (driving capacity: 4 mA)
HV
 VCC_ext: 9 V to 45 V (absolute max. ratings)
 VOL_HV, logic “0” Voltage < 3 V (no load)
 VOH_HV, logic “1” Voltage = VCC_ext – 0.1 V (driving capacity 1 A)
