Data Format Suffixes for Embedded V-memory Data
Several data formats are available for displaying V-memory data on the LCD. The choices are
shown in the table below. A colon is used to separate the embedded V-memory location from
the data format suffix and modifier. An example appears on the previous page.
The S, C0, and 0 modifiers alter the presentation of leading zeros and spaces. S removes
leading spaces and left justifies the result. C0 replaces leading spaces with leading zeros.
0 is a modification of C0. 0 eliminates any leading zeros in the C0 format version and converts
them to spaces.
Data Format Modifier Example Displayed Characters
none
(16-bit format)
V2000 = 0000 0000 0001 0010
1 2 3 4
V2000 1 8
[:S] V2000:S 1 8
[:C0] V2000:C0 0 0 1 8
[:0] V2000:0 1 8
:B
(4 digit BCD)
V2000 = 0000 0000 0001 0010
1 2 3 4
[:B] V2000:B 0 0 1 2
[:BS] V2000:BS 1 2
[:BC0] V2000:BC0 0 0 1 2
[:B0] V2000:B0 1 2
:D
(32-bit decimal)
V2000 = 0000 0000 0000 0000
Double Word
V2001 = 0000 0000 0000 0001
1 2 3 4 5 6 7 8 9 10 11
[:D] V2000:D 6 5 5 3 6
[:DS] V2000:DS 6 5 5 3 6
[:DC0] V2000:DC0 0 0 0 0 0 0 6 5 5 3 6
[:D0] V2000:D0 6 5 5 3 6
:DB
(8 digit BCD)
V2000 = 0000 0000 0000 0000
Double Word
V2001 = 0000 0000 0000 0011
1 2 3 4 5 6 7 8
[:DB] V2000:DB 0 0 0 3 0 0 0 0
[:DBS] V2000:DBS 3 0 0 0 0
[:DBC0] V2000:DBC0 0 0 0 3 0 0 0 0
[:DB0] V2000:DB0 3 0 0 0 0
:R
(DWord floating
point number)
V2001/V2000 = 222.11111
(real number)
Double Word
1 2 3 4 5 6 7 8 9 10 11 12 13
[:R] V2000:R f 2 2 2 . 1 1 1 1 1
[:RS] V2000:RS f 2 2 2 . 1 1 1 1 1
[:RC0] V2000:RC0 f 0 0 0 2 2 2 . 1 1 1 1 1
[:R0] V2000:R0 f 2 2 2 . 1 1 1 1 1
:E
(DWord floating
point number
with exponent)
V2001/V2000 = 222.1
(real number)
Double Word
1 2 3 4 5 6 7 8 9 10 11 12 13
[:E] V2000:E f 2 . 2 2 1 0 0 E + 0 2
[:ES] V2000:ES f 2 . 2 2 1 0 0 E + 0 2
[:EC0] V2000:EC0 f 2 . 2 2 1 0 0 E + 0 2
[:E0] V2000:E0 f 2 . 2 2 1 0 0 E + 0 2
f = plus/minus flag (plus = no symbol, minus = - )
