Communication IBoxes
Instruction Ibox # Page
ECOM100 Configuration (ECOM100) IB-710 5-272
ECOM100 Disable DHCP (ECDHCPD) IB-736 5-274
ECOM100 Enable DHCP (ECDHCPE) IB-735 5-276
ECOM100 Query DHCP Setting (ECDHCPQ) IB-734 5-278
ECOM100 Send E-mail (ECEMAIL) IB-711 5-280
ECOM100 Restore Default E-mail Setup (ECEMRDS) IB-713 5-283
ECOM100 E-mail Setup (ECEMSUP) IB-712 5-286
ECOM100 IP Setup (ECIPSUP) IB-717 5-290
ECOM100 Read Description (ECRDDES) IB-726 5-292
ECOM100 Read Gateway Address (ECRDGWA) IB-730 5-294
ECOM100 Read IP Address (ECRDIP) IB-722 5-296
ECOM100 Read Module ID (ECRDMID) IB-720 5-298
ECOM100 Read Module Name (ECRDNAM) IB-724 5-300
ECOM100 Read Subnet Mask (ECRDSNM) IB-732 5-302
ECOM100 Write Description (ECWRDES) IB-727 5-304
ECOM100 Write Gateway Address (ECWRGWA) IB-731 5-306
ECOM100 Write IP Address (ECWRIP) IB-723 5-308
ECOM100 Write Module ID (ECWRMID) IB-721 5-310
ECOM100 Write Name (ECWRNAM) IB-725 5-312
ECOM100 Write Subnet Mask (ECWRSNM) IB-733 5-314
ECOM100 RX Network Read (ECRX) IB-740 5-316
ECOM100 WX Network Write(ECWX) IB-741 5-319
NETCFG Network Configuration (NETCFG) IB-700 5-322
Network RX Read (NETRX) IB-701 5-324
Network WX Write (NETWX) IB-702 5-327
Counter I/O IBoxes (Works with H0-CTRIO and H0-CTRIO2)
Instruction Ibox # Page
CTRIO Configuration (CTRIO) IB-1000 5-330
CTRIO Add Entry to End of Preset Table (CTRADPT) IB-1005 5-332
CTRIO Clear Preset Table (CTRCLRT) IB-1007 5-335
CTRIO Edit Preset Table Entry (CTREDPT) IB-1003 5-338
CTRIO Edit Preset Table Entry and Reload (CTREDRL) IB-1002 5-342
CTRIO Initialize Preset Table (CTRINPT) IB-1004 5-346
CTRIO Initialize Preset Table (CTRINTR) IB-1010 5-350
CTRIO Load Profile (CTRLDPR) IB-1001 5-354
CTRIO Read Error (CTRRDER) IB-1014 5-357
CTRIO Run to Limit Mode (CTRRTLM) IB-1011 5-359
CTRIO Run to Position Mode (CTRRTPM) IB-1012 5-362
CTRIO Velocity Mode (CTRVELO) IB-1013 5-365
CTRIO Write File to ROM (CTRWFTR) IB-1006 5-368
