AUTOMEC CoastOne - Technical Data

82 Calvary St
Waltham, MA 02453
PHONE: (781) 893-3403
FAX: (781) 899-5708
4
2 TECHNICAL DATA
Authorized compiler for technical le:
Jukka Hakala
Tuottajantie 27 A 1
60100 Seinäjoki
Finland
TECHNICAL DATA
DIM. C9 C9 X
Press tonnage
kN(US tons) 220(24) 220(24)
Motor power
kW 5 5
Max. bending lenght (D) mm 850 850
Distance between side
frames
mm 790 790
Frame width (A)
mm
1440 1440
Frame height (B)
mm
2200 2500
Frame depth (C )
mm
1280 1280
Throat depth mm 150 150
Table height mm 850 850
Weight kg
1800 2000
daylight mm 500 650/800
Y-axis stroke mm 250 250
Y-axis repeatin accuracy mm +/-0.002 +/-0.002
Y-axis max working speed mm/s 10 (20*) 10 (20*)
Y-axis approach speed mm/s 100 100
Y-axis return speed mm/s 100 100
X-axis speed mm/s 500 500
X-axis accuracy mm +/-0.025 +/-0.025
X-axis stroke mm 400 400
X-axis max position
dimension
mm 550 550
Delta X-axis speed mm/s 100 100
Delta X-axis accuracy mm +/-0.025 +/-0.025
Delta X-axis stroke mm +/-50 +/-50
R-axis speed mm/s 100 100
R-axis accuracy mm +/-0.05 +/-0.05
R-axis stroke mm 140 140
Z-axis speed
mm/s 1000 1000
Z-axis accuracy
mm +/-0.5 +/-0.5
Z-axis stroke
mm 120 to 730 120 to 730
*can be up to 20mm/s, depending on requlations.
