4.2.13 Adjusting the reference values
Before reference values can be adjusted properly, machine must be referenced, there has to
be active program with real tool values, material thickness and machine has to have those tools
xed into it.
Notication! Hemming tools with sprigs or pneumatics cannot be used for reference adjustment!
Idea of the reference adjustment is that each axis is teached where actual 0.00 position should
be. Excluding Z1-Z2 axes who are teached 400.00 position.
After machine is referenced and actual tools corresponds the tools in program, axis can be
selected in manual mode page which requires adjustment. Axis must be manually jogged into
position which should be 0.00 (or 400.0 for Z).
Y-axis zero point:
The sheet is rmly hold between punch and die. Sheet thickness has to be the same as in
program.
X-axis zero point:
Back gauge ngertip is at bend line.
R-axis zero point:
Back gauge nger lower surface is at the level of the top of the die.
Z1/Z2-axis 400.0 position:
Distance from the left edge of die holder is 400 to the left edge of back gauge nger.
Delta X axis zero point:
Back gauge ngertip is at bend line.
S1/S2-axis zero point:
Sheet follower is at horizontal plane.
