Autonics LE8N Series User Manual

K-9
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
LCD Timer
※
1: Terminal 2 and 5 are connected inside. (Non-isolated)
※
2: Terminal (1, 2, 3) and (4, 5) are insulated inside.
※
Use reliable contacts enough to flow 5
㎂
current.
Input type No-backlight Backlight function
No-voltage
input
type
1
2
3 4 5
SIGNAL
INPUT
RESET
1
2
3 4 5
RESET
+ -
24VDC
BACKLIGHT
SIGNAL
INPUT
Voltage
input
type
+ -
1
2
3 4 5
4.5-30VDC
SIGNAL
INPUT
RESET
UP/DOWN
+
-
+
-
1
2
3 4 5
SIGNAL
INPUT
RESET
4.5-
30VDC
24VDC
BACKLIGHT
Free voltage
input type
1
2
3 4 5
6-240VDC
SIGNAL INPUT
RESET
24-240VAC 50/60Hz
+ -
~
!
!
-
Connections
● Bracket ● Panel cut-out
Min. 37
Min. 55
45
+0.6
0
22.2
+0.3
0
22
544
Dimensions
(unit: mm)
●LE8N-BN
※
1
●LE8N-BN-L
※
2
●LE8N-BV
※
1
●LE8N-BV-L
※
2
※
Terminal (1, 2) and (4, 5) are insulated inside.
●LE8N-BF
※
Backlight power is available as signal input
(SIGNAL INPUT, RESET).
Time operation
RESET
Max. time
range
0
H
L
H
L
SIGNAL
INPUT
48
24
36
