Safety Warning
● .
out, please turn off the power first.
● When the spark plug is running, the voltage can reach tens of thousands of volts, so don't touch it
directly with your bare hands to avoid injury.
Introduction
This is a digital high frequency tester for testing the performance and strength of spark plugs, with a frequency
up to 9000 rpm. It is compatible with all crankshaft engine and motorcycle spark plug testing among the market.
This product can also be compared to five holes at the same time, simulating real speed and digital control, which
greatly improve the test accuracy and work efficiency.
Features
● Operating frequency up to 9000 rpm, the higher the frequency, the stronger intensity of the spark plug.
● Three-year warranty and lifetime maintenance.
● Digital screen display for more precise control.
● Simultaneous comparison of five holes to improve efficiency.
● Simulate real rpm with high accuracy.
● Simple operation, plug and play.
Specifications
Introduction
1-Standard test hole; 2-3-4-5-test hole; 6-Display screen;
7-RPM "＋"; 8-RPM "－"; 9-Power switch; 10-Power port.
Operation introduction
● Insert the new spark plug into the hole ①, and insert the old spark plug into the hole ②③④⑤.
● Plug the power adapter into the rear of the host ⑩ power port and the indicator light will go on.
● Turn on the power switch and press the up and down buttons to adjust the operating frequency.
The higher the frequency, the stronger intensity of the spark plug.
Do not pull out or insert the spark plug with the power supply connected If you want to insert or pull it
OFF
ON
RPM
SP
ARK PLUG TESTER
SPT360
RPM
RPM
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
Input power: AC 220V±10% 50Hz/60Hz
Output power: DC12V±2 1A
Analog speed: 0~9999 rpm
Ambient temperature: 0℃~+45℃
Relative humidity: <85%
Host size: 200mm×150mm×100mm
Weight: 1100g
