Autopilot ECLIPSE F90 - LED Display & Control Surface; Function Knobs

FUNCTION KNOBS
LED DISPLAY & CONTROL SURFACE
(
CO
2
& TEMP LOCK
)
(
HUM & TEMP LOCK
)
(
ERROR LEDS
)
(
CO
2
PPM SETTING
) (
CO
2
DEADBAND
)
(
HUMIDITY SETTING
)
(
HUMIDITY MODE
)
(
CO
2
MODE
)
(
HEATING OUTPUT
)
(
COOLING OUTPUT
)
(
CO
2
OUTPUT
)
(
HUMIDITY OUTPUT
)
(
TEMP DEADBAND
)
(
TEMP SETTING
)
Click (press) knob, turn to
set, click again to confirm
Press both function knobs
for Min/Max recall
Press both knobs for 3
seconds to calibrate CO
2
Sensor/Switch F°/C°
(
PHOTOCELL
)
(
STATUS
)
(
POWER INPUT
)
(
SENSOR CORD
)
