Parts Description
Air outlet
Handle recess
Castors
Water tank
FRONT VIEW
Top panel
Right panel
Front panel
Airflow direction vane
(horizontal )
Airflow direction vane
(vertical )
Control panel
Remote controller
Cord hanger
REAR VIEW
LEFT SIDE VIEW
Exhaust air outlet
Rear panel
Air intake(condenser)
Air inlet
Air filter (inside)
Left panel
Power cord
5
