AUX ASW-H18E3B4/FAR3DI-C0 User Manual

61
14
●
★
●
Indoor Unit room
temperature
sensor error
Indoor Unit room temperature sensor,
Indoor Unit main PCB.
15
●
★
○
Indoor Unit coil
sensor error
Indoor Unit coil sensor, Indoor Unit main
PCB.
16
○
★
●
Indoor motor
error
Mechanical jam of motor, Indoor Unit
motor, Indoor Unit main PCB.
17
○
★
○
Refer to tooling
display for other
errors
Entire set of Outdoor Unit controller.
18
●
●
★
Compressor cap
sensor error
System pressure, compressor cap sensor
(protection switch), Outdoor Unit main
PCB.
19
●
○
★
Recirculated
sensor error
Recirculated sensor, four-way valve switch
error, Outdoor Unit main PCB.
20
○
●
★
※ Compressor
overpower
protection
Power voltage, module panel, Outdoor
Unit main PCB.
21
○
○
★
※ Over current
protection
Power voltage, system pressure, module
panel, Outdoor Unit main PCB.
22
●
●
○
Exhaust sensor
error
System pressure, exhaust sensor, Outdoor
Unit main PCB.
23
●
○
●
※ Cooling
overload
protection
Condenser, Outdoor Unit motor, capillary,
Outdoor Unit coil sensor, Outdoor Unit
main PCB.
24
○
●
●
※ Indoor high
temperature
heating protection
Evaporator, Indoor Unit motor, thin unit
connection pipe, Indoor Unit coil sensor,
Indoor Unit main PCB.
25
●
○
○
※ Indoor
cooling freezing
protection
Evaporator, Indoor Unit motor, capillary,
Indoor Unit coil sensor, Indoor Unit main
PCB.
26
○
●
○
Compressor shell
temperature
protection
Same as "18 Compressor cap sensor error".
27
○
○
●
※ OVP or UPV
error
Power voltage, reactor, module panel,
Outdoor Unit main PCB.
