AUX ASW-H18E3B4/FAR3DI-C0 User Manual

72
Part List
NO.
Part Name
ERP
Quantity
NO.
Part Name
ERP
Quantity
1
right side board
1
1
15
top cover
1
15
2
E-parts cover
1
2
16
Rear grille
1
16
3
valve plate
1
3
17
4-way valve tubing
assembly
1
17
4
stop valve
1
4
17.1
4-way valve
1
17.1
5
stop valve
1
5
17.2
suction pipe
assembly
1
17.2
6
Chassis assembly
1
6
17.3
discharge pipe
assembly
1
17.3
6.1
chassis
1
6.1
18
partition board
1
18
6.2
Base footing
2
6.2
19
Main controller
1
19
6.4
Pump foot bolt
3
6.4
19.1
control box cover
1
19.1
7
compressor
1
7
19.2
Main control board
1
19.2
8
panel grille
1
8
19.3
control box
1
19.3
9
panel
1
9
19.4
Radiator
1
19.4
10
axial flow fan
1
10
19.5
terminal board
1
19.5
11
left side board
1
11
19.6
E-parts bracket
1
19.6
12
motor
1
12
20
accessories
1
20
13
motor support
1
13
20.1
putty
1
20.1
14
Condenser
assembly
1
14
21
tape
1
21
14.1
condenser
assembly
1
14.1
22
reactor
1
22
14.2
Capillary assembly
1
14.2
23
Temperature sensor
1
23

AUX ASW-H18E3B4/FAR3DI-C0 Specifications

General

Brand	AUX
Model	ASW-H18E3B4/FAR3DI-C0
Category	Air Conditioner
Language	English
