AV Access U2EX60 - Specification

Specification
www.avaccess.com
6
info@avaccess.com
Specification
Technical
Input/Output Port
TX: 1 x DC 18V, 1 x USB Type-B, 1 x UTP Out
RX: 4 x USB Type-A, 1 x UTP In
General
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/±4kV (Contact discharge)
Power Supply
DC 18V 1A (Transmitter powers receiver through PoC)
Power Consumption
(Max)
6.4W (Pair)
Device Dimensions
(W x H x D)
TX: 90mm x 20mm x 55mm /3.54” x 0.79” x 2.17”
RX: 90mm x 20mm x 71mm /3.54” x 0.79” x 2.8”
Net Weight
TX: 0.11kg/0.242lb
RX: 0.14kg/0.308lb
Cable Specification:
Cable Type
Range
Supported USB Devices
Cat 5e/6/6a/7
Up to 263ft (80m)
USB-HID device
Up to 197ft (60m)
USB 2.0 storage device
