Ava 200 Series User Manual

Join the orange and grey revolution
AVA 200 Series Wiring
BASIC ACTUATORS:-
Standard wiring for Basic actuators used for all
series. Failsafe achieved using internal Super
Capacitor opon. Dierent wiring opons available.
WIRING BASIC ON OFF / HI SPEED / FAILSAFE TYPE: B3S
WIRING SMART ON OFF / HI SPEED / FAILSAFE TYPE: B3J
WIRING SMART MODULATING / HI SPEED / FAILSAFE TYPE: 4-20/0-10
SMART ACTUATORS:-
Smart actuators ulised Digital Encoder and
electronic relays. Feedback digitally set using
rmware. Dierent wiring opons available.
SMART MODULATING ACTUATORS:-
Smart actuators require resistor ng as shown
in diagram. Feedback must be connected for
actuator to work correctly.
Revision: 002 Date: 05/06/20
Note that we currently cannot oer Hi Speed Failsafe funconality due to limitaons in Capacitor technology used.
Note that we currently cannot oer Hi Speed Failsafe funconality due to limitaons in Capacitor technology used.
Note that we currently cannot oer Hi Speed Failsafe funconality due to limitaons in Capacitor technology used.
