Quad • Mounting guide | 3
Safety instructions
Disconnect power from the unit when performing a maintenance task.
Requires PoE+ power connection to operate with IR.
The power supply should bear the UL listed and LPS marks
This product should be supplied by a Power over Ethernet Power Sourcing Equipment (PSE) compliant to IEEE 802.3at Type 2 (PoE+).
The camera should be connected only to PoE networks without routing to the outside plant. The PoE PSE must be properly
grounded.
Please contact AVA’s certiied dealers (or distributor) for power adapters.
For the grounding wire use a green/yellow wire (min. 18AWG), a knurled washer and min. 3.5mm screw.
