Ava QUAD - In-Ceiling Mount; Preparation and Initial Assembly

Quad • Mounting guide | 9
In-ceiling mount
1
If needed, add hanging rods to strengthen the ceiling structure.
Weight of camera: 2.7 Kg
Weight of Recessed kit: 1.1 Kg
Hanging rod
Main keel
Secondary keel
ø15cm
Cut a hole in the center of the tile with a diameter of 15cm.
