28
Rinsing, Cleaning, and Draining
3. Remove the water reservoir lid by
unclipping the 5 locking tabs with a
screwdriver or similar object. The water
reservoir is the square holding tank at the
back of the unit.
4. You may also need to disconnect the tubing
that is attached to this lid. You can do so by
removing the locking clip and pressing on the
push connect ring while pulling the tubing o
the side of the lid.
Cleaning
