Rainier
(945/990)
Owner's
Manual
Freestanding Stove
Mobile-Home Approved
Alcove Approved
• Hearth-Stove Approved
• Masonry Fireplace
Insert
• Zero-Clearance (Metal)
Fireplace Insert
SAFETY NOTICE:
If this appliance is not properly installed, a house fire
may result. For your safety, follow the installation
directions. Contact local building or fire officials about
restrictions and installation inspection requirements
in your area.
Copyright 2007, T.I.
$10.00 100-01140
4050124
Listed
Tested to: U.L. 1482

Table of Contents

Questions and Answers

  • J
    jenniferhughesSep 10, 2025
    Why Avalon Stove does not burn hot enough?
    • A
      Allen RiveraSep 10, 2025
      There are several reasons why your Avalon stove might not be burning hot enough. * The wood may be wet. Refer to the "Selecting Wood" section on page 29 for more information. * Insufficient draft can be a factor. Chimney height and outside conditions can negatively affect the draft, causing the fire to burn slowly. Adding more pipe or a draft-inducing cap might help. * The air control might not be fully open. Ensure the air control is all the way in and slide it back and forth to make sure it is not stuck.
  • G
    Gabriel SmithAug 22, 2025
    Why is my Avalon Stove not burning hot enough?
    • J
      Jason WilsonAug 23, 2025
      If your Avalon Stove isn't burning hot enough, several factors could be at play. First, ensure your wood is dry; refer to the "Selecting Wood" section on page 27 for guidance. Insufficient draft can also cause this issue; adding more pipe or a draft-inducing cap might help. Lastly, verify that the air control is fully open and not stuck by sliding it back and forth.
  • F
    Fernando AtkinsAug 25, 2025
    What to do if smoke enters the room while reloading my Avalon Rainier 990 Stove?
    • J
      Joseph FlemingAug 25, 2025
      If smoke enters the room while reloading your Avalon Stove, allow the air to stabilize before fully opening the door. Push the air control in before opening the door, then open the door about an inch to let air into the firebox for a few seconds. Once the smoke consistently flows up the chimney, fully open the door. Insufficient draft may also be the cause, so adding more pipe or a draft-inducing cap might help.
  • S
    Stephen RichardsonAug 27, 2025
    How to stop smoke from entering the room during Avalon Rainier 990 start-up?
    • C
      Cindy ClarkAug 27, 2025
      If smoke enters the room during the start-up of your Avalon Stove, it could be due to a cold air blockage. Try burning a piece of newspaper to establish a draft. Also, ensure the air control is fully open (all the way in). If more air is needed, slightly crack the door open.
  • D
    dknightAug 28, 2025
    Why doesn't my Avalon Rainier 990 Stove burn long enough?
    • G
      Glenn RayAug 28, 2025
      If your Avalon Stove isn't burning long enough, ensure the doors are sealing properly to prevent air from entering the firebox; see the "Door and Glass Inspection" section on page 30 for details. Also, check the ash bed for coals, which may be glowing under a layer of flyash. Raking these coals into a pile can help restart the stove quickly.
  • H
    hardingmelissaAug 29, 2025
    What to do if kindling does not start in my Avalon Rainier 990 and fire smolders?
    • K
      Kelly HarrisAug 29, 2025
      If the kindling in your Avalon Stove isn't starting and the fire smolders, it might be due to a cold air blockage. Try burning a piece of newspaper to establish a draft. If needed, use additional newspaper. Also, make sure the air control is fully open. If more air is required, slightly crack the door open.
  • S
    Scott WatsonSep 18, 2025
    Why doesn't the blower run on my Avalon Rainier 990 Stove?
    • J
      Jim BruceSep 18, 2025
      If the blower on your Avalon Stove isn't running, it could be due to a couple of reasons. First, the stove might not be hot enough yet; the blower typically activates after 15 to 30 minutes of operation. Another cause could be an interruption in the electricity supply to the blower. Check your household breaker or fuse to ensure it's working correctly.
  • K
    kjordanSep 12, 2025
    How to stop smoke entering the room during Avalon Rainier 990 Stove start-up?
    • A
      Andrew HendersonSep 12, 2025
      If smoke enters the room during the start-up of your Avalon stove, it could be due to a cold air blockage. To resolve this, burn a piece of newspaper to establish a draft. Also, ensure the air control is fully open. If more air is needed, slightly crack the door.
  • M
    Michele Ferguson DDSSep 8, 2025
    Why doesn't the blower run on my Avalon Wood stove?
    • J
      jcruzSep 8, 2025
      The blower on your Avalon Wood stove might not be running because the stove hasn't reached the required temperature yet; the blower usually activates after 15 to 30 minutes. Also, check the household breaker or fuse to ensure electricity is flowing to the blower.
  • Y
    yharrisonSep 5, 2025
    What to do if the kindling does not start and the fire smolders in my Avalon Wood stove?
    • S
      Shannon KelleySep 5, 2025
      If the kindling in your Avalon Wood stove isn't starting and the fire is smoldering, it could be due to a cold air blockage; try burning a piece of newspaper to establish a draft. Also, ensure you're using enough starter paper; add more newspaper if needed. Make sure the air control is fully open, and if additional air is needed, slightly crack the door.

Summary

Introduction

Important Information

Details for model, serial number, and warranty registration.

Safety Precautions

General Safety Warnings

Essential safety guidelines for operation and installation.

Features & Specifications

Installation Options

Lists various ways the stove can be installed.

Heating & Performance Specs

Capacity, BTU, efficiency, and burn time details.

Dimensions and Clearances

Physical measurements and required distances to combustibles.

Stove Installation

Installation Planning and Preparation

Steps and checks before installing the stove.

Installation Types Overview

Different installation methods and their requirements.

Floor Protection Requirements

Guidelines for protecting the floor surface during installation.

Stove Placement and Clearances

Rules for positioning the stove safely and distances to combustibles.

Chimney and Drafting Requirements

Specifications for chimney connection and draft performance.

Specific Installation Scenarios

Guidelines for alcove, mobile home, and exterior chimney types.

Insert Installation

Insert Installation Planning and Preparation

Overview of planning, preparation, and considerations.

Insert Size and Placement Requirements

Dimensions, placement rules, and hearth specifications.

Fireplace Type Requirements

Specifics for masonry and zero-clearance fireplaces.

Block-Off Plate Installation

Instructions for creating and installing a block-off plate.

Insert Connection Types

Details on positive and direct connection methods for inserts.

Operating Your Appliance

Before First Fire Procedures

Verifying installation, curing paint, and opening the door.

Starting and Managing Fire

Tips for starting fires, adjusting burn rate, and reloading.

Burning Best Practices

Hints for burning, selecting wood, and cutting/storage.

Troubleshooting Operational Issues

Solutions for common smoke, draft, and blower problems.

Maintaining Your Appliance

Daily and Monthly Maintenance

Routine cleaning and inspection tasks for the appliance.

Yearly Maintenance Tasks

Annual upkeep including paint, air ducts, and firebrick inspection.

Door and Firebox Component Service

Replacing glass, gaskets, handles, and firebricks.

Limited 7 Year Warranty

Warranty Coverage Details

Explains coverage for parts and labor over seven years.

Warranty Conditions and Service

Terms, exclusions, and how to claim warranty service.

Optional Equipment

Stove Legs and Pedestal Installation

Instructions for installing optional legs or pedestal.

Outside Air and Blower Installation

Connecting outside air and installing blowers.

Surround Panels and Front Blower

Installation of surround panels and front blower.

Avalon Rainier 990 Specifications

General IconGeneral
Fuel TypeWood
Heating Area1, 200 - 2, 000 sq ft
MaterialSteel
EPA CertifiedYes
Emissions2.5 grams/hour
