5.2.1 Vocals
Preamplifier
Preamp Gain: +38
Input Selector: Mic
High Gain: Out
Phase: Out
48V: If needed
Filter: In
High Pass Frequency: 80
Compressor
Threshold: -5dB
Compression Ratio: 4:1
EQ->Comp: Out
Meter: In
Compressor: In
Attack: 10 O’clock
Release: 10 O’clock
VU Meter Gain Reduction: -3dB to -5dB
(adjust preamp gain, threshold and com-
pression to get more or less gain reduction)
Note: For a “punchy” singer use faster
attack. For a tighter sound use faster attack
and faster release.
Equalizer
Bass (level): 0 (Center Detent)
Bass Hz: N/A (not applicable)
Low Mid (level): Center Detent
Low Mid Hz: N/A
Low Mid Hi-Q: Out
Low Mid x10: Out
High Mid (level): 0
High Mid Hz: N/A
High Mid Hi-Q: Out
High Mid x10: Out
Treble (level): +6dB
Treble Hz: 32kHz
SC->Mids: Out
Equalizer: In
Applications
Page 25Avalon Vt-737sp Operation Manual
