Avantco CFD-2FF - Page 7

6
17813890 -- SF Only
12
LEFT BOTTOM HINGE: 178HINGCFDBL
46
COMPRESSOR UNIT INSTALLATION BOARD:
N/A
13 SPRING HINGE: 178 CARTRIDGE 47 CONDENSER: R-17811539, F-17817943
14
BRACKETS
48
CONDENSER FAN MOTOR: R-17810976,
F-
17815815
15
MIDDLE BRACKETS
49
BLADE OF CONDENSER FAN MOTOR:
R-17817114, F-17812660
16 BACK BRACKETS 50 CONDENSER FAN COVER: 17812098
17 LEFT SHELF TRACK: 178SHELFRAIL 51 FILTER FIXER: N/A
18 RIGHT SHELF TRACK: 178SHELFRAIL 52 FILTER
19 SHELF: Left or Right – 178SHELFCFD 53 CONDENSATE DRAIN PAN: 17812622
20 MIDDLE SHELF: 178SHELFCFD3 54 COMPRESSOR: R-17815901, F-17818299
21
RIGHT CONNECTING BOARD FOR CASTER
★★
55
SPLICE BOX ★★
22
LEFT CONNECTING BOARD FOR CASTER
★★
56
STARTER ★★
23
LEG SUPPORTER
★
57
OVERLOAD PROTECTOR ★★
24
LEFT TRACK FOR ASSEMBLING PANEL
★★
58
START CAPACITOR ★★
25
RIGHT TRACK FOR ASSEMBLING PANEL
★★
59
AC CONTACTOR: 17819644
26
EVAPORATOR: 17810051
60
BOTTOM HINGE FOR MIDDLE DOOR:
178HINGCFDBM
27 INNER DRAIN PAN: 17811448 61 MIDDLE DOOR BLOCK: N/A
28
FAN MOTOR INSTALLATION PANEL
★
62 KEY: 17811836
29 EVAPORATOR FAN MOTOR: 17813407 63
SUPPORT ROD
★★
30
EVAPORATOR COVER: 17818904
64
EVAPORATOR TEMPERATURE SENSOR★
17813890 – SF Only
31 EVAPORATOR FAN COVER: 17815699 65
DRAIN PAN HEATER: 17815643 ★
32 THERMOSTAT (See Below) 66
DRAIN HOSE HEATER: 17813722 ★
33
POWER SWITCH: Green Old – 17810364
Red New - 17810365
67
DEFROST HEATER: 17817359★
34 LOCK: 13009 68
★
Freezer only
★★
Consult Factory
32. Thermostats:
17816023 – SF 102, Refrigerator Thermostat
17818846 – SF104, Freezer Thermostat★
17815350 – Carenl Refrigerator Thermostat
17819471 – Carel Freezer Thermostat★
