Monday, 2 December 2013 PH658N - User Manual v1.1 2/15
Installation
1. Unpack the box and check for the following items enclosed:
a. Main unit with built-in magnetic hook switch
b. Handset
c. Handset cord
d. RJ45 Ethernet cable
2. Connect the handset to the base unit using the coiled handset cord provided
3. Connect one end of the Ethernet cable to the WAN port of the main unit, and the other end
to the wall Ethernet outlet
To discover the IP address of the handset
1. Lift the handset
2. Hear the dial tone
3. Press * 1 2 3 4 5 #
4. Listen to the IP address being announced by the handset receiver
Keypad Mapping
Figure 1 – PH658N Keypad & LED mapping
