How to fix Drago Baby Six Burner control panel that does not switch on?
To address a Drago Baby Six Burner control panel that doesn't switch on, first ensure the main switch is activated. If that doesn't work, try disconnecting and reconnecting the blue 16A IEC plug into a different socket. If the issue persists, it indicates a problem with the room's electrical system, and you should consult an electrician to identify and resolve it.
What to do if Avanzini Drago Baby Six Burner red display shows “- - - -”?
If the red display on your Avanzini Drago Baby Six Burner shows "- - - -", it means you need to replace the probe. To do this, switch off the main power and disconnect the plug before replacing the probe. Then, reconnect the power to the system. It's important to disconnect the power completely; simply turning off the control panel won't allow the probe to read the temperature correctly.
Why Avanzini Drago Baby Six Burner is heating slower than the normal parameters?
If the Avanzini Drago Baby Six burner heats slower than normal (taking over 14 hours to reach temperature), check that the button is NOT lit up in the OFF position. If the button is off but the high flame doesn't turn on, ensure the green display is set to 260°-300°C. Also, verify the burner is delivering the correct kilocalories by checking the meter or flame, ensuring it reaches at least the center of the cupola. Confirm your plant, meter, and pipe cross-section are correctly sized relative to the length, and check for pressure drops when other appliances are in use.
What to do if Avanzini Drago Baby Six high flame turns on but after 15- 20 seconds does not turn on?
If the Avanzini Drago Baby Six control panel turns on, and the high flame ignites but shuts off after 15-20 seconds: * Access the area under the oven near the SIT control unit. * Locate the plug connecting the valve body to the Drago control panel. * Gently press the black button and disconnect the plug, then firmly reconnect it while holding the socket. If the issue continues, remove and clean the burner before reassembling it. If it still doesn't ignite, replace the SIT control unit. Also, ensure the temperature set on the green display is high enough, exceeding the oven's internal temperature shown on the red display.
What to do if Avanzini Drago Baby Six spark strikes, low flame does not turn on and the burner stops?
If the Avanzini Drago Baby Six control panel turns on, the spark ignites, but the low flame doesn't ignite and the burner stops, ensure all gas system valves between the burner and counter, including safety solenoid valves, are open. Then, disassemble the burner to clean it by turning it over and blowing compressed air from the air intake and flame breaker, if needed. Inspect the red power cable for damage and check the ignition electrode's integrity and positioning. If the electrode is cracked, replace it. Finally, reassemble the burner and attempt ignition again.
What to do if Avanzini Drago Baby Six low flame turns on but the burner blocks and low flame turns off?
If the Avanzini Drago Baby Six control panel turns on, the low flame ignites, but the burner blocks and the low flame turns off, clean the burner by disassembling it, turning it over, and using compressed air on the air intake and flame breakers. Remove soot from the flame detection electrode and flame breaker using a metal brush. Ensure the air intake hole isn't blocked and the damper is correctly positioned (Methane gas: 3-4, LPG gas: 5-6). If the issue persists, replace the burner equipment.
What to do if Avanzini Drago Baby Six control panel turns on but the burner does not?
If the Avanzini Drago Baby Six control panel turns on but the burner does not, first check if the LED on the burner socket is lit. Ensure the low flame is active. If it's not, check the low flame temperature on the green display by pressing the two arrows and the “ON/OFF 2° FLAME” key simultaneously; it should be between 360° and 400°. If it’s lower than the oven temperature on the green display, the burner won't start. Try replacing the burner control equipment. Also, the automatic thermostat in the center of the two yellow burner torches might have tripped; wait for it to cool down to allow the burner to start.
What does it mean if the probe fault LED turns on for Avanzini Drago Baby Six Burner?
If the red signal light for the probe fault on your Avanzini Drago Baby Six Burner turns on and 4 lines appear on the red display, you need to replace the probe. Always disconnect the power by switching off the main switch and unplugging the unit before replacing it. Reconnect the power after replacement. It's crucial to disconnect the power completely; otherwise, the probe won't read the temperature correctly.
What to do if red display (T° inside the oven) exceeds the green display (set T°) with high flame LED off in Avanzini Drago Baby Six?
If the red display (showing the temperature inside the oven) exceeds the green display (set temperature) with the high flame LED off on your Avanzini Drago Baby Six Burner, locate F1 under the oven. Unscrew the brass cover with a flat-head screwdriver, insert the screwdriver into the hole below, and turn it anti-clockwise to lower the gas, reducing the flame until the oven temperature stops rising and slowly decreases.
Why the set T° does not increase on the green display of Avanzini Drago Baby Six Burner?
If the set temperature on the green display of your Avanzini Drago Baby Six Burner does not increase even when holding the button down, but decreases when pressed, it indicates that the maximum safety temperature is set too low. Adjust the maximum safety temperature to between 360°C and 400°C following the provided instructions.
Manufacturer's contact details and where to send requests for information or assistance.
Machine model, serial number, and details from the identification plate.
Machine's declaration of conformity and relevant directives it complies with.
Manual intended for operators, its supply, preservation, and updates.
Original manual language and explanation of the manual's page layout.
Defines required skills and qualifications for machine operators.
Lists safety devices ensuring operator safety and machine emergency stops.
Details about electrical cut-out switch, main switch, and safety temperature.
Information on noise levels, vibrations, and electromagnetic compatibility.
Describes residual risks and necessary personal protective equipment.
Specifies intended use, work environment, and foreseeable improper misuse.
User and operator obligations and prohibitions for safe operation.
Key technical specifications, dimensions, and main components of the machine.
Describes the operational sequence for heating ovens.
General precautions for lifting, handling, packaging, and shipping.
Crucial factors for the installation environment for proper burner operation.
Steps for hole drilling, temperature probe placement, and flue setup.
Explanation of the Drago Baby Six control panel, buttons, and indicators.
Steps for initial burner setup and temperature setting.
Procedures for low flame, air, gas parameters, and high flame adjustment.
Lists and explains error codes displayed on the control panel.
General introduction to maintenance types and safety precautions for personnel.
Schedule and tasks for regular inspection, check, and cleaning.
Procedures for extraordinary maintenance, repairs, and gas conversion.
Steps for converting the burner for different gas types.
Addresses issues like control panel not switching on or burner not starting.
Detailed explanation of error codes and their causes/solutions.
Includes control unit diagram, connections diagram, and technical data sheet.
General| Type | Pellet Burner |
|---|---|
| Fuel | Wood Pellets |
| Efficiency | 92% |
| Weight | 45 kg |
| Dimensions (HxWxD) | 600x400x600 mm |
| Voltage | 230 V |
| Frequency | 50 Hz |
| Power consumption | 80 W |
