Table 8: SFP transceivers
Model Description Part number
Important:
Avaya supports SFP transceivers with the following part numbers: AA1419013–E5, AA1419014–E5,
AA1419015–E5, and AA1419025–E5 to AA1419040–E5. However, Avaya strongly recommends using
the newer DDI versions of these SFP transceivers.
1000BASE-T SFP gigabit Ethernet, RJ–45 connector AA1419043–E6
1000BASE-SX DDI SFP 850 nm, gigabit Ethernet, duplex
LC connector
AA1419048–E6
1000BASE-LX DDI SFP 1310 nm, gigabit Ethernet, duplex
LC connector
AA1419049–E6
1000BASE–ZX DDI CWDM 70 km
SFP
gigabit Ethernet, duplex LC
connector
AA1419065-E6
1000BASE-BX10 DDI SFP 1310 nm (tx) and 1490 nm (rx) AA1419069–E6 (10 km at 1310
nm ) and mating pair AA1419070–
E6 (10 km at 1490 nm)
100BASE-FX SFP 1300 nm, 100 Mbps Ethernet,
multimode fiber, duplex LC
connector
AA1419074–E6
Small form-factor pluggable plus (SFP+) transceivers
SFP+ transceivers are hot-swappable input and output enhancement components that allow 10
gigabit connections. All Avaya SFP+ transceivers use Lucent connectors (LC) to provide precision
keying and low interface losses.
For more information about SFP and SFP+ transceivers, including technical specifications and
installation instructions, see Installing Transceivers and Optical Components on Avaya Ethernet
Routing Switch 3600 Series.
Table 9: Supported SFP+ transceivers and cables
Model Description Part number
10GBASE-SR/SW SFP+ 400 m, 850 nm MMF AA1403015–E6
10GBASE-LRM SFP+ 220 m, 1260 to 1355 nm; 1310 nm
nominal MMF
AA1403017–E6
10GBASE-LR/LW SFP+ 10 km, 1310 nm SMF AA1403011–E6
10GBASE-ER/EW SFP+ 40 km, 1550 nm SMF AA1403013–E6
10GBASE-ZR/ZW SFP+ 70 km, 1550 nm SMF AA1403016–E6
10GBASE-CX SFP+ 2-pair
twinaxial copper cable that plugs
into the SFP+ socket and
connects two 10-gigabit ports
SFP+ DAC 10 meter AA1403018–E6
Table continues…
Installing ERS 3600 in an equipment rack
January 2017 Installing Avaya Ethernet Routing Switch 3600 Series 28
Comments on this document? infodev@avaya.com
