About icons
The icons in the following table indicate the state of a call, navigation choices, or the status of
a team member whose presence you are tracking.
Icon Description
Indicates a missed call on your phone
Incoming call; indicates you have answered this call.
Outgoing call; indicates you have made this call.
Indicates that EC500 has been activated.
Incoming call is alerting.
Call is active.
Call is on hold.
Conference is active.
Conference is on hold.
Use the Right or Left navigation arrow to see additional
pages/screens/options.
Scroll left for other options.
Scroll right for other options.
Scroll up or down when there is more information than
can display in the application area.
End of a list; scroll up to see choices.
The icon shown applies to the 9608 only. The call in
progress is muted.
The icon shown applies to the 9608 only. The ringer
volume is off due to pressing - on the Volume button
until the volume turns off. To reinstate volume, press +
on the Volume button.
The icon shown applies to the 9611 only. The ringer
volume is off due to pressing - on the Volume button
About icons
Avaya one-X
®
Deskphone H.323 9608 and 9611G User Guide April 2013 11
