Telephone stand
The phone can be placed on the stand in a flat position or at an angle.If you have placed the
phone vertically for wall mounting, reverse the tab located under the switchhook in the top ear
piece pocket on the phone to ensure that the handset is in the correct position. You need a
small screwdriver to lift the tab after it is reversed.
Viewing Network Information
Your system administrator might ask you to check certain phone or network settings to
investigate problems. You can obtain network information from the Home Screen.
Network Information has five different screens for viewing the options:Audio parameters, IP
(Internet Protocol) parameters, Quality of Service, Interfaces, and Miscellaneous.
Use the right and left navigation arrows on the navigation button to view the network related
information on the various screens.
Your system administrator will instruct you further as to which network information options and
settings are needed.
Telephone stand
Avaya one-X
®
Deskphone H.323 9608 and 9611G User Guide April 2013 13

Other manuals for Avaya one-X 9611G

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Avaya one-X 9611G and is the answer not in the manual?

Avaya one-X 9611G Specifications

General IconGeneral
Resolution320 x 240 pixels
SIP SupportYes
BluetoothNo
Display TypeColor
PoE ClassClass 1
ProtocolsSIP, H.323
Display3.5-inch (diagonal) color display
Ethernet Ports2 (10/100/1000 Mbps)
PoEYes (802.3af)
Headset InterfaceRJ9
SpeakerphoneFull-duplex
CodecG.711, G.729, G.722
Weight1.0 kg (2.2 lbs)
