Available in 4 different end forms to place
all fasteners (except Rivscrew). Suitable on
applications with no or little access restric-
tion.
SELECTING A NOSE JAW
List the name, size and material of the fastener to be placed.
Look for this fastener in the first column of the nose jaw selection tables on page 12
if you use imperial measurements and on page 13 if you use metric units.
Looking right across the table, take note of which nose jaws are available. ONLY
those shown are available.
Select which is most suitable for your application by referring to the respective nose
jaw drawing. If your application has no access restriction, you should select the
standard shape with a flat end form with or without a cam.
■
■
■
■
'D'
'E'
'B'
28.6
1.125
33.5
1.32
LONG
UNIVERSALFLAT
RECESSED
FLAT
'D'
'E'
'B'
20.5
0.81
LIMITED ACCESS
41.4
1.63
Available to place most of the fasteners.
Allows more penetration into applications
with no other access restriction.
Available as shown in NOSE JAW SELEC-
TION TABLE.
Allows more penetration into applications
with restricted access.
Mandrels must be curved by hand to follow
the shape of the jaw.
Available as shown in NOSE JAW SELEC-
TION TABLE.
Allows access into very restrictive applica-
tions.
'D'
'E'
'B'
28.6
1.25
34
1.34
STANDARD CAM OPERATED
FLAT
HEAD FORMING (HF)
FLAT
'D'
'E'
'B'
28.6
1.25
LIMITED ACCESS CAM OPERATED
37.1
1.46
'D'
'E'
'B'
28.6
1.25
LONG CAM OPERATED
FLAT
34
1.34
Available as shown in NOSE JAW SELECTION TABLE overleaf. Equivalent functions to the Standard, Long and Limited Access above
with the addition of a cam to ease and speed up the nose jaw opening thus the pod reloading procedure.
