Avdel 07530 - Page 27

25
1 07530-00214 COVER 1 -
2 07001-00268 SCREW 1 -
3 07005-00670 SEALING RING 2 -
4 07530-00213 REAR PLUG 1 -
5 07530-00211 TAIL JAW TUBE 1 -
6 07530-00215 ELBOW CONNECTOR
2-
7 07154-04040 SPRING 1 -
8 07530-00800 TAIL JAW PISTON ASSEMBLY 1-
9 07530-00206 RUBBING STRIP 1 1
10 07530-00204 STROKE LIMITER 1 -
11 07530-00203 PISTON 1 -
12 07530-00202 BODY 1 -
13 07003-00142
SEAL
22
14 07005-01084 4mm AIR HOSE (2500mm) 1-
15 07007-00319 CABLE TIES 9 -
16 07005-01327 HYDRAULIC HOSE ASSEMBLY (2150mm) 1-
17 07530-00601 HANDLE MOULDING (RIGHT) 1-
18 07530-00300 VALVE AND TRIGGER ASSEMBLY 1-
19 07530-00301
SWITCH AND TRIGGER BLOCK
1-
20 07530-00308 SPRING 1 -
21 07003-00121 'O' RING 3 3
22 07125-00215 SPRING 1 -
23 07005-01357 CONNECTOR 1 -
24 07003-00022 'O' RING 1 -
25 07220-00803 RETAINER 1 -
26 07007-00300 TRIGGER 1 -
27 07530-00306 SPOOL 1 -
28 07001-00479 SCREW 1 -
29 07003-00042 'O' RING 1 -
30 07530-00309 SEAL RETAINER 1 -
31 07530-00310 PLUG 2 -
32 07004-00059 WASHER 1 -
35 07530-00302 SPOOL 1 -
36 07004-00058 WASHER 1 -
37 07001-00404 SCREW 1 -
38 07530-00201 BARREL 1 -
39 07003-00237 SEAL 1 -
40 07530-00500 BLEED PLUG ASSEMBLY 1-
41 07003-00142
●
SEAL 1 1
42 07003-00194
●
SEAL 1 1
43 07001-00442
●
SCREW 1 -
44 07530-00501
●
PLUG 1 -
45 07530-00207 TAIL JAW CYLINDER 1-
46 07530-00205 PLUG 1 -
47 07530-00208 JAW HOUSING 1 -
48 07151-00403 TAIL JAWS 2 2
49 07003-00113 'O' RING 2 2
50 07004-00078 CIRCLIP 1 -
51 07530-00603 END CAP 1 -
52 07002-00134 NUT 7 -
53 07530-00604 SCREW 2 -
54 07001-00401 SCREW 3 -
55 07001-00262 SCREW 2 -
56 07530-00210
LABEL
2-
57 07530-00602 HANDLE MOULDING (LEFT) 1-
70 07005-00760 QUICK RELEASE NIPPLE 1-
74 07003-00167 'O' RING 1 1
75 07003-00236 SEAL 1 1
76 07271-01100 CURSOR 1 -
77 07490-03002 SPRING 1 -
78 07241-00208 SPINDLE 1 -
79 07530-00216 FERRULE 2 -
80 07530-00801 TURRET PLUG 1 -
ITEM PART Nº DESCRIPTION QTY SPARES ITEM PART Nº DESCRIPTION QTY SPARES
07530-00200 PARTS LIST
