N T E N T O F U S E
The pneumatic 0753 type tool is designed to place Avdel repetition fasteners (except
1
/
16
” Avlug) making it ideal for batch or flow-line
assembly in a wide variety of applications throughout all industries.
Both models, the 07530 and 07532 are hand-held lightweight tools. Their only difference lies in the location of the hose entry. The top
entry on the 07532 tool allows supension from an added mounting plate, see drawing opposite. Part numbers are shown to order a
complete tool including the intensifier and all hoses but no nose equipment.
The base tool part number for the 07530 model is 07530-00200 and is 07532-00200 for the 07532 model. See the general assemblies
on pages 24 to 27.
Both models will place the same fasteners and both will place most repetition fasteners, as shown in the table below.
Both models make use of the same nose equipment. Reference must be made to the Nose Equipment section of the manual when selecting
compatible components for the type and size of fastener used in your application (see pages 10 to 19). Nose jaw dimensions are shown
on page 11 and stated on pages 12 and 13.
FASTENER NAME
2.5mm
2.8mm
●●●
●
●●
FASTENER SIZE
CHOBERT
GROVIT
AVLUG
BRIV
RIVSCREW
AVTRONIC
AVSERT
●●●●●
●●●●
●●
●●●●
3
/32"
1
/4"
3
/16"
5
/32"
1
/8"
M3
6-32
UNC
M2.5
4-40
UNC
4mm3.5mm3mm
