5
To convert electrical energy into hydraulic energy that in turn will drive various hand held Hydraulic Powered Tools. The design pressures of
these Tools must be compatible with the working pressures stipulated in the Tool Specifications below.
Model HP21 HP41 HP51
Electric Motor 2.2 kW 4 pole flange mount
Power Supply 220/230V 380/415V 525V
1PH 3PH 3PH
50 Hz 50 Hz 50Hz
Full Load Amps 15.00 5.3 3.8
Working Pressure
Pull 55.2 mPa (8000 psi)
Return 20.7 ma (3000 psi)
Delivery Volumes 2.6 l/min 3.3 l/min 3.3 l/min
Hydraulic Fluid ISO VG 46 OR EQUIVALENT
Pump 4 Cylinder radial
Control 24V dc solenoid controlled directional valve coupled to
a hydrafast combination pressure control and relief valve
Length (L) 815 mm (32")
Height (H) 530 mm (21")
Width (W) 360 mm (14")
Mass 98 kg with full oil tank
Avdel UK Limited policy is one of continuous product development and improvement and we reserve the right to change the specification of any product without prior notice.
Int e nt o f U se
Tool Spe c if i cat i on
Tool Dim e ns i ons
Specifications
