REF. QTY.
DESCRIPTION
HE-2-X
P -051692*
HE-2-X
P -062026*
HE-2-LX
P -051614*
HE-2-FX
P -066625
New P/N Old P/N New P/N Old P/N New P/N Old P/N New P/N Old P/N New P/N Old P/N
1
1 Bracket, Pipe R431006882 P -066812-
00005
R431006882 P -066812-
00005
R431006882 P -066812-
00005
R431006882 P -066812-
00005
R431006882 P -066812-
00005
2
1 Strainer, Port R431006895 P -066849-
00000
R431006895 P -066849-
00000
R431006895 P -066849-
00000
R431006895 P -066849-
00000
R431006895 P -066849-
00000
3
1 Gaskets, Port R431006889 P -066823-
00000
R431006889 P -066823-
00000
R431006889 P -066823-
00000
R431006889 P -066823-
00000
R431006889 P -066823-
00000
4
3 Screw, 5/16x2-1/4 R431002440 P -049902-
00048
--- --- --- --- --- --- R431002440 P -049902-
00048
5
1 Body, Complete
Bushed & incls. #6
R431002869 P -051112-
00002
--- --- --- --- --- --- --- ---
6
4 Stud, 5/16-18x1-3/8 R431002505 P -049906-
00014
--- --- --- --- --- --- --- ---
7
1 Valve, Inlet supply SEE KITS --- --- --- --- --- --- --- --- ---
15*
2 Ring, Retainer SEE KITS --- --- --- --- --- --- --- --- ---
16*
2 “SCREEN” SEE KITS --- --- --- --- --- --- --- --- ---
17*
2 Ring, Snap R431002398 P -049882-
00059
--- --- --- --- --- --- --- ---
18*
1 FOLLOWER R431003014 P -052835-
00000
--- --- --- --- --- --- --- ---
19
1 SCREW R431002950 P -051856-
00000
--- --- --- --- --- --- --- ---
20
1 Lever, RT. R431004871 P -058979-
00001
--- --- --- --- --- --- --- ---
21
1 Roller
WITH LEVER
--- --- --- --- --- --- --- --- ---
22
1 Plug, Valve R431005364 P -060028-
00000
--- ---
23
1 Screw, 1/4-28x1/2-
Lever
WITH LEVER
--- --- --- --- --- --- --- --- ---
24
1 Pin, 3/16 Lever, RT
WITH LEVER
--- --- --- --- --- --- --- --- ---
25
2 Washer R431002409 P -049898-
00009
--- --- --- --- --- --- --- ---
26
2 Nut, 5/16-18 R431002419 P -049901-
00020
--- --- --- --- --- --- --- ---
27
1 Pin, Lever R431002722 P -050686-
00007
--- --- --- --- --- --- --- ---
28
2 Pin, 1/16 x 1/2 R431002541 P -049913-
00001
--- --- --- --- --- --- --- ---
29
1 Spring, Exhaust
Valve
SEE KITS --- --- --- --- --- --- --- --- ---
30
1 Spring, Diaphragm See Pg. 6 See Pg 6 See Pg. 6 See Pg. 6 See Pg. 6 See Pg. 6 See Pg. 6 See Pg. 6 See Pg. 6 See Pg. 6
31
1 Seat, Spring R431000036 -526347-
00000
R431004868 P -058978-
00001
R431004868 P -058978-
00001
R431004868 P -058978-
00001
R431004868 P -058978-
00001
32
1 Housing, Spring
w/ Nut
R431006822 P -066488-
00002
R431004871 P -058979-
00001
R431004871 P -058979-
00001
--- --- --- ---
33
4 Nut, 5/16-18 R431002419 P -049901-
00020
R431002722 P -050686-
00007
R431002722 P -050686-
00007
R431002722 P -050686-
00007
R431002722 P -050686-
00007
34
1 Valve, Inlet & Exh.
(Incls. #35)
SEE KITS --- --- --- --- --- --- --- --- ---
35
1 Ring, 3/4 O.D. SEE KITS --- --- --- --- --- --- --- --- ---
36
1 Follower, Diaphragm SEE KITS --- --- --- --- --- --- --- --- ---
37
1 Diaphragm SEE KITS --- --- --- --- --- --- --- --- ---
HE-2-FX
P -051612*
HE-2 CONTROLAIR
®
VALVE
PARTS LIST
Page 9
NOTE: *Approximate suffix from IDENTITY SCHEDULE, Page 6, must be used to identify valve and pressure ratings. See sheet 7 for plated part
numbers for Items 43,52,53.
(CONTINUED)
To Next Page
