32
Command Set
Command
Command Packet
Comments
SYS_Menu
Off
8x 01 06 06 03 FF
Erasing menu display(turn off
the menu screen/VC-A70H)
SYS_Menu
On/Off
8x 01 06 06 10 FF
turn on/off the menu screen
SYS_Menu
Menu Enter
8x 01 7E 01 02 00 01 FF
menu enter
Video Format
Change 4)_ (Video
System Rotary
Switch 7: only
VISCA Control
enabled)
-
8x 01 7E 01 1E 0p 0q FF
pq 00→1920 x 1080p/59.94
pq 02→1920 x 1080p/29.97
pq 03→1920 x 1080i/59.94
pq 04→1280 x 720p/59.94
pq 05→1280 x 720p/29.97
pq 08→1920 x 1080p/50
pq 0A→1920 x 1080p/25
pq 0B→1920 x 1080i/50
pq 0C→1280 x 720p/50
pq 0D→1280 x 720p/25
Pan-tiltDrive
Up
8x 01 06 01 VV WW 03 01
FF
VV: Pan speed setting 0x01
(low speed) to 0x18 (high
speed)
WW: Tilt speed setting 0x01
(low speed) to 0x18 (high
speed)
YYYYY: Pan Position EAC00
to 15400 (CENTER 00000)
ZZZZZ: Tilt Position FC400 to
0B400 (Image Flip: OFF)
(CENTER 00000)
Tilt Position F4C00 to 03C00
(Image Flip: ON) (CENTER
00000)
SRG-300H → see notes
VC-A70H → see notes
PT20X-SDI-GY-G2 → see
notes
Pan-tiltDrive
Down
8x 01 06 01 VV WW 03 02
FF
Pan-tiltDrive
Left
8x 01 06 01 VV WW 01 03
FF
Pan-tiltDrive
Right
8x 01 06 01 VV WW 02 03
FF
Pan-tiltDrive
UpLeft
8x 01 06 01 VV WW 01 01
FF
Pan-tiltDrive
UpRight
8x 01 06 01 VV WW 02 01
FF
Pan-tiltDrive
DownLeft
8x 01 06 01 VV WW 01 02
FF
Pan-tiltDrive
DownRight
8x 01 06 01 VV WW 02 02
FF
Pan-tiltDrive
Stop
8x 01 06 01 VV WW 03 03
FF
Pan-tiltDrive
Home
8x 01 06 04 FF
Pan-tiltDrive
Reset
8x 01 06 05 FF
Pan-tiltSet
SlowPanTilt
On
8x 01 06 44 02 FF
Pan/Tilt Slow Mode On/Off
