AVer VC520 Pro2 User Manual

3
Expansion Speakerphone/Microphone Connection
There are 2 types of expansion solutions that can be extended from the VC520 Pro2 speakerphone.
Please purchase the expansion speakerphone and/or microphone directly from AVer or an AVer
reseller.
Expansion Speakerphone Requirements:
- VC520 Pro2 Firmware version: 7200.00 or later
- FONE540 Firmware version: 7000.44 or later
[Note]
 The VC520 Pro2 can support up to two expansion speakerphones, however, the daisy-chain
expansion cable cannot exceed over 40m in total.
 Please connect the power supply for the expansion speakerphone when daisy-chaining over 20m.
 Please connect the power supply when upgrading the firmware for the expansion speakerphone.
 The expansion speakerphone cannot be used as the main speakerphone; it can only be used with
the VC520 Pro2.
 The speakerphone/microphone cables will be included in the package contents when the user
purchases the expansion speakerphone/microphone.
VC520 Pro2 speakerphone
Expansion speakerphone
Speakerphone cable
Expansion speakerphone
Power adapter
Microphone cable
Expansion
microphone
Expansion
microphone
Expansion
microphone
Expansion
microphone
VC520 Pro2 speakerphone
[Note] The VC520 Pro2 can support up to four expansion microphones, however, the daisy-chain
expansion cable cannot exceed over 40m in total.

AVer VC520 Pro2 Specifications

General

Megapixel	2 MP
Camera type	Single camera
Optical zoom	12 x
Combined zoom	24 x
PTZ protocols	UAC, Pelco-P/D, UVC, VISCA
White balance	Auto, Manual
Focal length range	3.9 - 47.3 mm
Aperture range (F-F)	1.8 - 2.8
Light exposure modes	Auto
Vertical field of view	48 °
Horizontal field of view	76 °
Number of camera presets	10
Wide Dynamic Range (WDR)	Yes
Closest focusing distance	1.5 m
Field of view (FOV) angle	84.5 °
Maximum frame rate	60 fps
Video formats supported	H.264, M-JPEG, NV12, YUV, YUY2
Maximum video resolution	1920 x 1080 pixels
Supported graphics resolutions	320 x 240, 424 x 240, 480 x 360, 640 x 360, 640 x 480 (VGA), 800 x 448, 848 x 480, 960 x 540, 1280 x 720 (HD 720), 1600 x 900, 1920 x 1080 (HD 1080)
Pan range	-170 - 170 °
Mounting type	Stand/Wall mounting
Product color	Black
Tilt angle range	-30 - 90 °
Certification	Zoom, Skype for Business, Microsoft Teams, ClickShare, RingCentral
Remote control type	IR
Cable lock slot type	Kensington
Number of microphone arrays	2
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	Camera to speakerphone, AUX, AC, USB
USB cable length	5 m
Power cable length	1.8 m
VISCA input ports	1
DIN connector type	9-pin
Minimum RAM	4096 MB
Minimum processor	Intel Core i5-4460
Minimum processor speed	3.2 GHz
Minimum processor family	Core i5
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7
Package width	259 mm
Package height	349 mm
Package weight	5400 g
Input current	5 A
AC input voltage	100 - 240 V
DC input voltage	12 V
Power source type	DC
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85258900
Warranty period	3 year(s)

Weight and Dimensions

Depth	142.7 mm
Width	153 mm
Height	182 mm
Weight	1450 g
Speaker dimensions (W x D x H)	220 x 181.5 x 49.5 mm
Remote control dimensions (W x H x D)	200 x 50 x 21 mm
