AVer VC520 Pro2 User Manual

First Time Login ............................................................................................. 24
Set Up the Preset .......................................................................................... 26
Select the Preset Position ............................................................................. 27
Camera Settings ............................................................................................ 27
Tracking Mode ....................................................................................... 28
Framing Speed ...................................................................................... 30
Smart Frame Preset Point ..................................................................... 31
Auto Focus ............................................................................................ 32
Home Position ....................................................................................... 32
Sleep Position ........................................................................................ 33
Sleep Timer ........................................................................................... 33
On Screen Menu ................................................................................... 34
Camera Binding ..................................................................................... 34
Save Preset ........................................................................................... 35
Image Settings .............................................................................................. 36
Image Flip .............................................................................................. 36
Image Mirror .......................................................................................... 36
True WDR .............................................................................................. 37
Frequency .............................................................................................. 37

AVer VC520 Pro2 Specifications

General

Megapixel	2 MP
Camera type	Single camera
Optical zoom	12 x
Combined zoom	24 x
PTZ protocols	UAC, Pelco-P/D, UVC, VISCA
White balance	Auto, Manual
Focal length range	3.9 - 47.3 mm
Aperture range (F-F)	1.8 - 2.8
Light exposure modes	Auto
Vertical field of view	48 °
Horizontal field of view	76 °
Number of camera presets	10
Wide Dynamic Range (WDR)	Yes
Closest focusing distance	1.5 m
Field of view (FOV) angle	84.5 °
Maximum frame rate	60 fps
Video formats supported	H.264, M-JPEG, NV12, YUV, YUY2
Maximum video resolution	1920 x 1080 pixels
Supported graphics resolutions	320 x 240, 424 x 240, 480 x 360, 640 x 360, 640 x 480 (VGA), 800 x 448, 848 x 480, 960 x 540, 1280 x 720 (HD 720), 1600 x 900, 1920 x 1080 (HD 1080)
Pan range	-170 - 170 °
Mounting type	Stand/Wall mounting
Product color	Black
Tilt angle range	-30 - 90 °
Certification	Zoom, Skype for Business, Microsoft Teams, ClickShare, RingCentral
Remote control type	IR
Cable lock slot type	Kensington
Number of microphone arrays	2
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	Camera to speakerphone, AUX, AC, USB
USB cable length	5 m
Power cable length	1.8 m
VISCA input ports	1
DIN connector type	9-pin
Minimum RAM	4096 MB
Minimum processor	Intel Core i5-4460
Minimum processor speed	3.2 GHz
Minimum processor family	Core i5
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7
Package width	259 mm
Package height	349 mm
Package weight	5400 g
Input current	5 A
AC input voltage	100 - 240 V
DC input voltage	12 V
Power source type	DC
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85258900
Warranty period	3 year(s)

Weight and Dimensions

Depth	142.7 mm
Width	153 mm
Height	182 mm
Weight	1450 g
Speaker dimensions (W x D x H)	220 x 181.5 x 49.5 mm
Remote control dimensions (W x H x D)	200 x 50 x 21 mm
