Upgrading the Hard Disk Drive
To replace the hard disk drive, do the following:
1. Turn OFF the computer. Unhook the AC cord and all
cables/devices attached to the notebook. Remove the battery
back.
2. Place your hand on a large metal object momentarily to
discharge any static electricity.
3. Locate and remove Screw A.
4. Remove HDD Cover.
Screw A
HDD Cover
5. Life the HDD module away from the bay and carefully
separate the module from the HDD connector.
