Operators Manual
ALS 221
Release 7/04 Page 31 Errors and warnings
Message Meaning How to solve
___1 Illegal interrupt (processing error) Hardware failure external noise. EPROM
damaged. Turn off power and on again.
Change EPROM or main board
___2 Illegal bank interrupt (processing
error)
Hardware failure external noise. EPROM
damaged. Turn off power and on again.
Change EPROM or main board
INTO Illegal interrupt INTP0 (processing
error)
Hardware failure external noise. EPROM
damaged. Turn off power and on again.
Change EPROM or main board.
5.2 Dispenser warnings
In case of a warning message the relevant output is switched. The signal can be used for inter-
connection with an external machine control. Warning W__5 activates only the special OD warn
output.
Message Meaning How to solve
W__2
Error while writing in the
EEPROM
EEPROM defect, Start ma-
chine again, if problem remains
the same, exchange EEPROM
as soon as possible
W__5
Material end by the OD con-
trol recognised
Insert a new material roll
W__6
Too many products between
sensor and dispensing edge
Move the sensor closer to the
dispensing edge
5.3 STO! Power-fail message
The message STO! appears in the display as the machine is switched off or if the mains supply
voltage has fallen below specification.
The message STO! (store) indicates that the machine has stored some parameters internally
as a power fail condition was detected. The error output is switched active and the ready output
inactive simultaneously with STO! appearing in the display.
If the mains supply voltage only experiences a drop in level and then returns to a correct level
then the ready output is restored to its previous condition but the message STO! will remain in
the display to indicate that there has been a problem with the mains supply.
