3.1.8
Attach the moving plate to the Z axis using the screws removed in previous steps.
M5 x 14mm Flat Head Screw
Benchtop PRO
Assembly Instructions
Version 2020Q2.1
© 2020 Avid CNC
All Rights Reserved
