5.2 Gantry Cable Track Installation
5.2.1
Insert the M8 x 30mm bolts into the provided anchors and place the anchors in the bracket extrusion provided.
M8 x 30mm Socket Head Cap Screw
CRP950-03 4040 Cable Track Extrusion
40 Series Anchor Fastener
