6.1 Tabletop Installation
6.1.1
Attach a piece of tabletop extrusion to the machine crossmembers as indicated.
8020 Table Extrusion
M5 Roll-in T-Nut
M5 x 16mm Flat Head Screw
Benchtop PRO
Assembly Instructions
Version 2020Q2.1
© 2020 Avid CNC
All Rights Reserved
