TYPE F TYPE N
STEP 27: INSTALL OUTER KNOB
Install the outboard adjuster knob by aligning the
rectangle tab of the foot screw with the
rectangular hole in the knob then pressing it on
firmly.
STEP 28: INSTALL CABLE SEALS
TYPE F - Push the upper cable seal on to the
cable ferrule and place it into the cable stop.
Push the lower cable seal on to the bottom of the
ferrule.
TYPE N - Push the upper and lower boots on to
the integrated cable stop.
20
