Avios BushMule V2 - Page 11

10
Roll left
Roll right
Pitch down
Pitch up
Yaw left
Yaw right
Aileron
(Roll)
Elevator
(Pitch)
Rudder
(Yaw)
20 -40 mm
20 -40 mm
15-30 mm
15-30 mm
50-60 mm ~
Rudder
Elevator
Aileron
10 - 15 mm
10 - 15 mm
* Elevator ‘low rates’ 15mm ‘high rates’ 30mm in either direction from neutral.
* Aileron ‘low rates’ 20mm ‘high rates’ 40mm in either direction from neutral.
* Rudder ‘low rates’ 10mm ‘high rates’ 15mm in either direction from neutral.
Aileron
Elevator Rudder
CONTROL THROWS:
