AVM FRITZ!Card PCI User Manual

3 How FRITZ!Card Works
20
The following diagram shows how the individual components of
FRITZ!Card interact:
FRITZ!Card functional diagram
Functions of the Driver Software
ISDN is equipped with three channels: two B channels and one
D channel. The B channels are used for data transmission such
as faxes. The ISDN terminal device, such as the ISDN-Controller
FRITZ!Card, uses the D channel to communicate with the digital
exchange: among the information transferred via this channel
are connection charges. The CAPI 2.0 driver software processes
the D-channel protocol of the ISDN connection and puts all
required B-channel protocols (X.75, HDLC, etc.) at the disposal
of the applications. CAPI 2.0 also provides SoftCompression
X75/V42bis, SoftModem and SoftFax G3.
CAPI SoftCompression X75/V42bis
The driver software for the ISDN-Controller FRITZ!Card supports
data compression as per V.42bis for X.75 connections in
accordance with the CAPI standard. Connection times and costs
can be reduced considerably with this type of data compression.
COMMON-ISDN-API 2.0
FRITZ!Card
B-channel protocols (digital):
X.75, HDLC, transparent,
V.110, V.120, T.90, ISO 8208 (X.25)
AVM
NDIS
WAN
CAPI
Driver
AVM
ISDN
CAPI
Port
Driver
Applications like
Exchange/
Explorer/
Browser/Outlook
FRITZ!data
FRITZ!fax
FRITZ!fon
FRITZ!vox
CAPI Soft
Compression
X75/V42bis
CAPI
SoftFax G3
C A P I
CAPI
SoftModem
V32
On-line software
Additional ISDN software
bsed on CAPI
