2.6 System requirement
Model No. 8 ports PS/2 IP-KVM switch
Local console side One VGA Monitor
One Keyboard
One Mouse
Network Side 10/100Mbps Ethernet
or Modem
Remote Console
side
One computer
Computer side 8 PCs with 8 3-in-one cables (One
HDDB 15-pin male to one HDDB 15-pin
and two Mini Din 6-pin PS/2 cables)
Model No. 16 ports PS/2 IP-KVM switch
Console side One VGA Monitor
One Keyboard
One Mouse
Network Side 10/100Mbps Ethernet
or Modem
Remote Console
side
One computer
Computer side 16 PCs with 16 3-in-one cables (One
HDDB 15-pin male to one HDDB 15-pin
and two Mini Din 6-pin PS/2 cables)
2.7 Cable diagrams
PS/2 Cable:
Mini Din 6 pin Male to Male
VGA Cable:
HDB15 pin Male to Male
AT to PS/2 keyboard adapter: (Optional)
Din 5 pin Male to Mini Din 6 pin Female
